Ravel Fire Alarm Control Panel Conventional 8 Zone C/Red l UL-Listed
USD $278.55
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
Electrical Specification Primary Power 120 – 220VAC ± 10%, 50 Hz, 2.5Amps. Standby Power
24V D.C (2 Nos of 12v, 12Ah Sealed Lead acid battery).
Quiescent current: 120mA Initiating Device Circuits All zones are Class B Style B/C operation (Programmable). Normal Operating Voltage: 14 – 21 VDC. Alarm Current: 15 – 30mA. Short Circuit Current: 45mA Maximum. Loop resistance: 100 ohms Maximum. End-Of-Line Resistor: 3K9, 1/2watt Standby Current: 7mA (2mA for Detectors) Operating Condition Operating Temperature 0 – 49° C/32-120° F. Relative Humidity 93 ± 2% RH (non- condensing) at 32 ±2° C/90 ±3° F. Charging Circuit Charging Voltage 28.2V, ±0.5V Charging Current 800mA (Max.). Notification Appliance Circuits Class B Style – Y wiring Operating Nominal Voltage: 24VDC Special Application Current for all NACs: 1.2Amps (0.6A per circuit) Line Drop: 1.8V End-Of-Line Resistor: 3K9, 1/2watt D.C. Output Supervised 24VDC regulated, 300mA Max. Common Relays Type : Form C No of Relays : 3 Relay Contact Rating : 2Amps @ 30 VDC, 0.5Amps @ 125VAC. Power Factor : 1.0
Mechanical Specification Dimensions : (440W X 340H X 120D) Color : Red / White Construction : 18 Gauge (1.22mm) CRCA sheet with powder-coated Finish IP Rating : IP50 Cable Entry : 11xø19mm Knockout in top of the cabinet 10xø22.25mm Knockout in top of the cabinet
24V D.C (2 Nos of 12v, 12Ah Sealed Lead acid battery).
Quiescent current: 120mA Initiating Device Circuits All zones are Class B Style B/C operation (Programmable). Normal Operating Voltage: 14 – 21 VDC. Alarm Current: 15 – 30mA. Short Circuit Current: 45mA Maximum. Loop resistance: 100 ohms Maximum. End-Of-Line Resistor: 3K9, 1/2watt Standby Current: 7mA (2mA for Detectors) Operating Condition Operating Temperature 0 – 49° C/32-120° F. Relative Humidity 93 ± 2% RH (non- condensing) at 32 ±2° C/90 ±3° F. Charging Circuit Charging Voltage 28.2V, ±0.5V Charging Current 800mA (Max.). Notification Appliance Circuits Class B Style – Y wiring Operating Nominal Voltage: 24VDC Special Application Current for all NACs: 1.2Amps (0.6A per circuit) Line Drop: 1.8V End-Of-Line Resistor: 3K9, 1/2watt D.C. Output Supervised 24VDC regulated, 300mA Max. Common Relays Type : Form C No of Relays : 3 Relay Contact Rating : 2Amps @ 30 VDC, 0.5Amps @ 125VAC. Power Factor : 1.0
Mechanical Specification Dimensions : (440W X 340H X 120D) Color : Red / White Construction : 18 Gauge (1.22mm) CRCA sheet with powder-coated Finish IP Rating : IP50 Cable Entry : 11xø19mm Knockout in top of the cabinet 10xø22.25mm Knockout in top of the cabinet
